JET FILTER MODEL / KFS

PURPOSE OF USAGE KFS model Jet Filter is used for separating the dust-air mixture with high efficiency through filter bags. By holding dust, fresh air is thrown into the atmosphere through the chimney. First purification is carried out thanks to the centrifugal power generated in the round filter body. Then the dust particles on the outer surface of the filter bags are kept. Filter, according to models, 2.5 m3 / min. It is used for filtration of dusty air at flow rates from ‘to 800 m3 / min. AREA OF USE * In the food industry; - Flour and semolina factories, - Feed factories, - Biscuit and pastry factories, - Hazelnut factories, - beer malt factories, - Other food industries, * In the chemical industry; - Paint factories, - Plastic factories, - Detergent factories, * In the wood industry, * Non-metal minerals processing industry, * In the stone and soil industry, * In the cement industry, * For general purpose use. FEATURES AND ADVANTAGES It can be used in filter, vacuum and pressure systems. Cleaning of filter bags is done with 0.5 bar pressure sweeping air that can be obtained free from oil and water. Sweeping air consumption; It is calculated by the formula 35 - 40 Nlt (Newton liters) x bag x number of strokes. It is possible to find the following values ​​from the appropriate flow geometry of the cleaning air outlet in filters; * Loading capacity of the filter according to the product, * Maximum cleaning capacity of filter bags, * High efficiency cleaning rate of the cleaned air, * Thanks to the cleaning air tank combined with the filter, there is no need for an additional tank. WORKING PRINCIPLE N1 Filtration process in N1 bag; Filtering the dusty air on the outer surface of the filter bags N2 End moment of cleaning in N2 bag; The bags, whose outer surface is loaded with dust, are cleaned by spraying from the inside, one after the other. Dust is exhausted through the airlock. Important Criteria in Filter Installation Filter loading depends on factors such as filtration process, chemical reactions, drying and the like, as well as the effect sizes given below. For example, the maximum filter load for 2.4 m bag length is (9 m3 / min) / m2 for the aspirator in the wheat cleaning process. Impact Factors * Grain size, such as paint pigment, mill pneumatic system, cleaning and aspiration, * Physical composition of the powder, * Dust concentration in uncleaned air (aspirator), * Electrostatic charge, The filter dimensions given below have been calculated based o
