Mobile Drying
We have two types of dryers (Large240 and XLM380), which are powerful and reliable models providing daily production ranging from 85 to 250 mt depending on the product to be dried.
They can be equipped with three different types of burners:
Biomass (Coal, pellet, or rice husk)
Diesel
Gas
Recommended for medium to upper-medium scale businesses that want to perform the drying process directly and keep product quality under control.
Additionally, when both are equipped with automatic functions, all these models can be included in continuous drying cycles, enabling the most modern farms to optimize their production.
All models feature fast filling and unloading capabilities, along with a fan and high-performance burner, ensuring the best performance.
The models currently in our product range remain the best-selling and most popular, perfectly representing the philosophy of drying: power and efficiency, robustness and durability, balance and safety.
| SUPER 120 (Gas or Diesel) | LARGE 240 (Multi-Fuel) | XLM380 (Multi-Fuel) | |
|---|---|---|---|
| Capacity mt | 17 m³ | 34 m³ | 56 m³ |
| Corn Capacity mt | 12 | 24 | 38 |
| Rice Capacity mt | 9.5 mt | 19 mt | 31 mt |
| Average Daily (Corn %20-%14) | 81 mt / 24 hours | 145 mt / 24 hours | 225 mt / 24 hours |
| Average Daily (Rice %20-%14) | 45 mt / 24 hours | 91 mt / 24 hours | 150 mt / 24 hours |
| Size in Transport Mode (LxWxH) | 5.05 x 2.5 x 4.1 | 9.16 x 3.34 x 4.83 (Bio-Fuel) | 10.46 x 4.04 x 5.4 (Bio-Fuel) |
| Size in Operation Mode (LxWxH) | 7.7 x 2.5 x 6.5 | 9.61 x 3.34 x 7.93 (Bio-Fuel) | 11.28 x 4.04 x 9.2 (Bio-Fuel) |
| Total Motor Power | 34.95 kW (Gas or Diesel) | 40.69 (Bio-Fuel) | 54.69 kW (Bio-Fuel) |
| Weight | 3800 kg | 6700 kg | 9500 kg |
| Avg. Coal Consumption | 15 - 25 kg / hour | 35 - 45 kg / hour | 15 - 25 kg / hour |
| Avg. Diesel Consumption | 10 - 12 lt / hour | 18 - 22 lt / hour | 28 - 31 lt / hour |
| Avg. Husk Consumption | 100 - 120 kg / hour | 130 - 150 kg / hour | 150 - 170 kg / hour |
| Avg. LPG Consumption | 12 - 14 kg / hour | 20 - 25 kg / hour | 33 - 38 kg / hour |
| Perforated Sieves | 2.5 mm 430 inox | 2.5 mm 430 inox | 2.5 mm 430 inox |
