SPİRAL KARIŞTIRICI

SMI horizontal mixer is the best unit for animal feed use with the following special features: 1) It is mixed even when adding liquid ingredients and when mixing products of different specific weight. 2) High production rates with mixing times not exceeding 5/6 minutes. 3) Easy emptying. 4) simple to maintain. The SMI horizontal mixer is made of heavy duty sheet steel. The cover is divided into sections to facilitate 1.0 control. The agitators are in the form of a double helix: the inner helix is ​​smaller in diameter than the outer helix and in the opposite sense. This creates a continuous motion movement on the outer periphery and a movement contrary to the mass movement at the center. Thus, the ingredients are perfectly mixed. All moving parts are mounted on ball bearings with two gearmotors. The horizontal agitator is equipped with a slide that opens over the entire length to ensure rapid discharge. Molasses can be added to the feed in accordance with the company specifications. Molasses adding unit consists of tank armature and blasting system. Molasses is added daily; The amount of molasses is measured by the flow rate controller, and its temperature can be controlled by means of heaters. The mixer ensures that the 40 ° C molasses is mixed homogeneously with the feed. There are two models depending on your capacity requirement. One with single shaft and the other with double shaft. Both the body and wing group can also be made in AlS1304 Class Stainless Steel. FEATURES St37 or AlS1304-Grade stainless steel body Adjustable paddles Continuous operation Single or double shaft options Dynamically and statically adjusted rotor Ergonomic maintenance grips Safety sensors
