PLZ-50/30 MODEL PRE-CLEANING SIEVE

PLZ-50/30 Model Zaccaria Pre-Cleaning Screen is designed to clean products that are smaller, larger or lighter than the desired product. It is vitally important to use it as a pre-cleaning or cleaning screen. The usage principles consist of the following stages: First Stage: The closed circuit aspiration system ensures that products that are lighter than the product in the product are sucked and discharged vertically with the help of the air produced by the fan. Second Stage: Sieves mounted in parallel on each other in different mesh sizes, move in an inclined level vibrating and ensure the separation of small and large foreign substances from the product. Third Stage: With the air suction at the product outlet, it provides cleaning of light grains that were not absorbed in the 1st and 2nd stages. Each return has a different exit. While small and large foreign materials are collected in sacks, light materials are absorbed by the cyclone. Features - Platform with firewall for maintenance and adjustments - Ladder that facilitates climbing on the machine - Stainless sieve sets that prevent abrasion or mold - Wooden sieve frames that allow screen replacement with the drawer system - Durable body structure - No need for extra fans with built-in dust suction on the chassis - Adjustment flaps with indicator on the air suction aspirator - Spare parts that can be supplied easily locally - Stainless sieve types specially designed for the products - There are protective covers on the belts to ensure user safety - Specially designed body and movement system, extremely stable and silent operation Provides Power Consumption: Sieve: 2,2 kw / IV pole 30 hp / IV pole Fan: 3.7 kw / IV pole 5.0 hp / IV pole Capacity: Rough Cleaning: 50.000 kg / hour Paddy Fine Cleaning: 30.000 kg / clock paddy
